Bone Metastases of Urothelial Carcinoma

Department of Urology, Ibn Rochd University Hospital, Morocco

*Corresponding Author: Dr. Safwate Reda, Department of Urology, Ibn Rochd University Hospital and Faculty of Medicine and Pharmacy, Casablanca, Morocco, Tel: +212662097858, Email: safwateredaa@gmail.com

Received Date: March 19, 2025

Published Date: April 10, 2025

Citation: Reda S, et al. (2025). Bone Metastases of Urothelial Carcinoma. Mathews J Case Rep. 10(2):204.

Copyrights: Reda S, et al. © (2025).

ABSTRACT

Background: Bone metastases of urothelial carcinoma are the third most common metastasis after the lungs and liver. Bone complications adversely affect quality of life. They are also associated with increased mortality. The objective of this study is to describe the epidemiological, clinical and prognostic aspects of bone metastases of urothelial carcinoma. Material and methods: This is a retrospective, monocentric study of 8 cases of bone metastases of urothelial carcinoma, collected from January 2022 to December 2024 at the Ibn Rochd University Hospital in Casablanca, Morocco. The analyzed data were collected on an exploitation sheet. Incomplete records were excluded from the study. Results: The average age of our patients was 61.37 years. All patients were male and smokers. Pain was the main calling sign and was found in seven patients. Four patients had anemia and 50% of the patients had acute obstructive kidney disease. All patients had undergone a CT scan that confirmed bone metastases in seven patients with predominantly osteolytic lesions. Treatment was palliative and consisted of chemotherapy, radiotherapy or a combination of both. Three patients died, two progressed with new lesions. Three had stabilized lesions. Conclusion: The presence of bone metastases of urothelial carcinoma constitutes an unfavorable moment in the evolution of this cancer. These metastases are responsible for numerous complications that require multidisciplinary management.

Keywords: Urothelial Carcinoma, Bone Metastases, Thoracoabdominopelvic Scanner.

INTRODUCTION

Urothelial cancer is the second most common cancer in urology, consisting of bladder tumors and tumors of the upper excretory tract. These lesions are known for their seriousness with a high metastasizing power and a high mortality rate, directly related to the systemic spread of the disease. When urothelial cancer becomes metastatic, metastases may be synchronous with the discovery of the disease or may occur during post-treatment surveillance of the primary lesion [1]. Numerous metastatic sites have been described in the literature, but the most common secondary sites of urothelial carcinomas are drainage nodes (90%) [2], lung (52%), liver (33%) and bone (26%) [3]. The prevalence of bone metastases in patients with advanced or metastatic urothelial cancer is 30-40% [4].

The objective of this study is to describe the epidemiological, clinical and prognostic aspects of bone metastases of urothelial carcinoma.

MATERIALS AND METHODS

This is a retrospective, descriptive study conducted at the Ibn Rochd University Hospital of Casablanca over a period of 3 years from January 2022 to December 2024. In our study, we selected patients with urothelial cancer with bone metastases at the onset or during the course of the disease. Data were collected from medical records retrieved from the annual registries of the Urology and Oncology Department. Patient information was collected on an operating sheet. This included epidemiological, clinical, biological, radiological (imaging), prognostic and therapeutic data (Figure 1-8).

Figure 1. Bladder ultrasound: tissue processes of the left posterolateral and intradiverticular bladder wall.

Figure 2. (CT scan): Large intravesical tumor.

Figure 3. Left lateroaortic adenopathy.

Figure 4. Lung metastases.

Figure 5. Liver metastase.

Figure 6. Bone metastase.

Figures 3, Figure 4, Figure5, Figure 6: The most common metastatic sites (CT scans): Node involvement (Figure 3), lung metastases (Figure 4), liver metastase (Figure 5), bone metastase (Figure 6).

Figure 7. Osteolytic bone metastasis (orange arrow) and osteocondensation bone metastasis (Black arrow) in the pelvis.

Figure 8. Osteolytic bone metastasis in the pelvis.

RESULTS

Our series includes 8 cases, all male, exclusive male and all smokers. The mean age of our patients is 61.37 years with extremes of 46 to 74 years. No occupation at risk (Table1).

Table 1. Epidemiology data

A radical treatment (cystoprostatectomy) decided during the multidisciplinary consultation meeting was proposed to all patients. Four patients (50% of cases) accepted the procedure, two of whom had received neoadjuvant chemotherapy. For the remaining patients, they were lost to follow-up after refusal of the proposed treatment. Of the 50% of cases who had a radical treatment, three patients were derived by transileal ureterostomy (Bricker) and one by enterocystoplasty (Table 2).

Table 2. Endoscopic aspect, operative procedure and anatomopathological study

The circumstances of discovery were dominated by pain, which was present in seven of our patients (87.5% of cases). The pain was located in the pelvis in 6 patients, one patient had pelvic and spinal back pain. One patient had no pain. Signs associated with pain were: altered general condition and functional impotence of one or two lower limbs. These signs were present in a variable manner (Table 3).

Table 3. Clinical presentation

Renal function was normal in 50% of the cases (4 patients) and acute obstructive renal failure in 4 of our patients (50% of the cases), one of whom had died. The hydroelectrolyte balance showed variable results.

Thoracoabdominopelvic CT scan (TAP CT) was performed in all our patients (100% of the cases). Bone metastases were found in 7 patients (87.5% of cases). The pelvic bones were the most affected with 87.5% of cases, lumbar and dorsal vertebrae in 37.5% of cases, costal lesions in 25% of cases and cranial lesions in one case (Table 4).

Table 4. Bones Affected by CT Scans

Table 5. Radiological appearance (CT scan) of bone metastases

Three of our patients (37.5% of the cases) had performed bone scans that showed bone metastases. One patient (12.5% of the cases) had benefited from magnetic resonance imaging (MRI) which showed bone lesions and pedicular damage. One patient underwent a CT-guided bone biopsy and pathological examination confirmed metastases of a carcinoma whose histological appearance was compatible with a carcinoma urothelial with squamous inflection sector.

Treatment of these bone metastases was palliative. Two patients (25% of cases) had received chemotherapy alone, another patient (12.5% of cases) had received radiotherapy alone. Four patients (50% of cases) had received palliative chemotherapy and analgesic and haemostatic radiotherapy (Table 6).

Table 6. Treatment

Table 7. Associated treatment

DISCUSSION

Urothelial carcinoma is a major public health problem [5]. Secondary bone tumors, or bone metastases, are the localization and development of tumor lesions in bone tissue from cells that have migrated by blood or lymphatic route from a primary tumor. These are the most common bone tumors (60%) [6].

Tumors of the bladder appear after the age of 60 in the majority of cases [7,8]. In France, with an estimated 12,305 new cases in 2015, 80% of which will be in men, bladder cancer ranks fourth in incidence and seventh in deaths from all cancers and is the second most common urological cancer after prostate cancer [7].

Transitional cell carcinoma is the most predominant histological type, found in more than 90% of cases [9,10].

Tumors of the upper excretory tract account for 5% of urothelial carcinomas [3,11]. The peak incidence is between 70 and 90 years of age with a male/female ratio close to 2:1 [3].

For our study focused on bone metastases of urothelial carcinoma, our data are consistent with the literature where most tumors appear after the age of 60 years and where urothelial carcinomas of the bladder are more common than tumors of the upper excretory tract.

These cancers occur more frequently in men than in women, but women have a poorer prognosis [5].

Our series of eight patients consisted exclusively of males with no female cases. This is consistent with most of the data in the literature where the male sex is predominant.

 At the initial diagnosis of urothelial tumors, 5% of tumors are metastatic from the outset [12,13]. The majority of metastases occur in the course of progression after treatment of urothelial carcinoma [1,4]. The most frequent secondary sites of urothelial carcinoma are the lung (52%), liver (33%), and bone (26%) [3].

 Bone metastases are the main cause of pain at the time of cancer. They are responsible for many serious complications in addition to pain: pathological fracture, spinal cord compression, ponytail compression, paralysis of cranial nerves, hypercalcemia, bone marrow infiltration with deficit of one or more blood lines. These complications lead to a significant reduction in quality of life [14]. Bone metastases can be asymptomatic [6].

Our data are consistent with those of most authors where pain is the main and revealing manifestation of bone metastases. It was present in seven of our patients and absent in only one.

The renal insufficiency in half of our patients was due to tumor obstruction or compression of the excretory pathways by adenopathy. The recommended extension workup for urothelial carcinoma is uroscanning coupled with chest CT [3,7]. The CT scan is necessary to confirm the malignancy of a bone lesion. MRI is complementary to CT, especially for the examination of the spinal cord and tumor extensions [15]. Bone scans are not routinely indicated in muscle-invasive bladder tumors, but remain the first-line examination when there is a clinical point of care [7,16]. A guided puncture biopsy under CT scan should be considered as a last resort if there is still doubt [16].

Our results are consistent with those in the literature because bone scans were not systematically requested, and were performed in only 3 patients in our series. Also for the bone biopsy, which was performed only in one patient. It was the TAP CT scan that had already objectified bone metastases.

Secondary bone lesions may be: most often diffuse (predominantly in the axial skeleton: mainly lumbar spine, pelvis, upper extremities of femurs, scapular belt, skull), sometimes isolated or associated with other visceral metastases. Lytic or condensing, depending on whether osteoclasia or osteoblastic reconstruction processes predominate [6].

Radiologically, there are three types of bone reactions: lytic, condensing or mixed [15]. Osteolytic metastases are the most common [14].

The results of our series were consistent with those in the literature because osteolytic lesions were predominant. In addition to the CT scan, one patient received an MRI scan that confirmed pedicular damage, but the patient died before the start of treatment. The reference treatment for metastatic urothelial cancers is based on Cisplatin-based chemotherapy.

The combination of M-VAC (methotrexate, vinblastine, adriamycin, cis-platin) is the reference treatment for patients eligible for this chemotherapy with a median survival of 14 to 15 months [1,7]. The initial standard first-line treatment protocol is MVAC, MVAC HD (intensified) or gemcitabine-carboplatin (GC). Pembrolizumab (anti-PDL-1) is recommended for second-line therapy [7]. Prior to the development of effective chemotherapy, patients with metastatic cancer rarely had a median survival of more than 3-6 months [17].

In the literature, Karnofsky's performance status (PS) less than or equal to 80% and the presence of visceral metastases were independent prognostic factors of low survival after MVAC treatment [18]. In the case of visceral metastases, mean survival is 4 months. Creatinine clearance of less than 60 ml/min is also a prognostic factor as it would contraindicate the use of cisplatin, which has been shown to be the most effective protocol. Thus, patients are classified into two groups according to their performance status and creatinine clearance: patients eligible for platinum-based combination chemotherapy (FIT) and those not eligible (UNFIT).

Whether at the time of diagnosis or in the follow-up of tumors already known and treated, the management of urothelial metastases is essentially based on chemotherapy [1]. Local irradiation (radiotherapy) of the metastasis, in addition to its direct antitumor effect, reduces pain by reducing edema and peritumoral inflammation.

It is the most effective and quickest treatment, especially in terms of analgesia. Surgery is useful for treating pathologic fractures, although simple immobilization does not allow for any bone consolidation, and additional radiotherapy must be administered in all cases [14]. Bone complications have a negative effect on pain and therefore on quality of life. They are also associated with increased mortality [19].

Biphosphonates reduce the risk of vertebral or non-vertebral pathologic fractures, spinal cord compression, malignant hypercalcemia, and reduce the need for surgery or radiation [14].

Bisphosphonates limit and delay these events by inhibiting bone resorption. Denosumab is a monoclonal antibody that binds to and neutralizes RANKL (nuclear factor-KB ligand receptor activator), thereby inhibiting osteoclast function and thus generalized bone resorption and local bone destruction. Thus, RANKL is as good as zoledronic acid at preventing or delaying bone complications [20]. Denosumab has fewer kidney complications than bisphoshonates.

Our series joins the data in the literature because our patients (FIT) had received Cisplatin-based chemotherapy, those who were UNFIT had received carboplatin with gemcitabine. They had also received analgesic and haemostatic radiotherapy. One patient had received zoledronic acid (biphosphonate) to prevent bone events. No patients had received Denosumab or had undergone bone surgery.

The prognosis is generally unfavorable with limited life expectancy and significant morbidity and mortality, as evidenced by our series. While the small number of cases is the limitation of our study, we have nevertheless achieved our goal of describing the epidemiological, clinical and prognostic aspects of bone metastases of urothelial carcinoma.

CONCLUSION

Bone involvement in urothelial carcinoma is common and represents a turning point in the evolution of this cancer. With a very poor prognosis, they are responsible for many serious complications that significantly affect the quality of life. The therapeutic management of these problems requires a multidisciplinary approach (often decided in a multidisciplinary consultation meeting) in order to stabilize these lesions, improve quality of life and prolong the survival of these patients.

DECLARATIONS

AUTHOR’S CONTRIBUTIONS

Safwate Reda and Safieddine Mehdi: Contributed to all stages of the article.

Nachid Abdellah, Ait Mahanna Hamza, Daghdagh Yassine, Kbirou Adil and Moataz Amine: Contributed to the bibliographi­cal research.

Mohamed Dakir, Adil Debbagh and Rachid Aboutaieb: Corrected the ar­ticle.

ACKNOWLEDGEMENTS

None.

CONFLICT OF INTEREST

All the authors stated that there is no conflict of inter­est.

REFERENCES

1. Lebret T, Méjean A. (2008). Cancer urothéliaux métastatiques : le futur et les perspectives [Metastases from urothelial carcinoma : future and prospects]. Prog Urol. 18(Suppl 7):S277-S284.
2. Lebret T, Méjean A. (2008). Sites métastatiques atypiques des tumeurs urothéliales [Rare locations of metastases from urothelial carcinoma]. Prog Urol. 18(Suppl 7):S289-S297.
3. Rouprêt M, Audenet F, Roumiguié M, Pignot G, Masson-Lecomte A, Compérat E, et al. French recommendations of the AFU Cancer Committee - update 2020-2022: tumors of the upper urinary excretory tract.
4. Mohamed H, Abdellatif K, Mohamed M, El Kadiri el Hassani Bedreddine El Ghazi El Abbès, Abderrahmane A, Youssef E, et al. Recommendations of good medical practice in onco-urology: tumors of bladder, Moroccan Urological Association (AMU) 2016.
5. Julita L, Jichlinski P, Lucca I. (2017). Urothelial carcinoma of the bladder and upper urinary tract, Forum Med Switzerland.  17(35):744-749.
6. Professor Jean-Philippe Vuillez: Secondary bone tumors, Corpus Médical- Faculté de Médecine de Grenoble, October 2003.
7. Rouprêt M, Pignot G, Masson-Lecomte A, Compérat E, Audenet F, Roumiguié M, et al. French recommendations of the cancer committee of the French association of urology (AFU) - Update 2020-2022: bladder tumors.
8. Siegel RL, Miller KD, Jemal A. (2018). Cancer statistics. Cancer J Clin. 68:7-30.
9. Ismaili N, Arifi S, Flechon A, El Mesbahi O, Blay JY, Droz JP, et al. (2009). Small cell cancer of the bladder: pathology, diagnosis, treatment and prognosis. Bull Cancer. 96(6):E30-E44.
10. Ismaili N, Amzerin M, Elmajjaoui S, Droz JP, Flechon A, Errihani H. (2011). Rôle de la chimiothérapie dans la prise en charge du cancer de la vessie [The role of chemotherapy in the management of bladder cancer]. Prog Urol. 21(6):369-382.
11. Visser O, Adolfsson J, Rossi S, Verne J, Gatta G, Maffezzini M, et al. (2012). Incidence and survival of rare urogenital cancers in Europe. Eur J Cancer. 48(4):456-464.
12. Jemal A, Siegel R, Ward E, Hao Y, Xu J, Thun MJ. (2009). Cancer statistics, 2009. CA Cancer J Clin. 59(4):225-249.
13. Irani J, Bernardini S, Bonnal JL, Chauvet B, Colombel M, Davin JL, et al. (2007). Tumeurs urothéliales [Urothelial tumors]. Prog Urol. 17(6):1065-1098.
14. Gremaud M, Delouche D, Monnerat C. (2006). Traitement des métastases osseuses par les bisphosphonates [Treatment of bone metastases with bisphosphonates]. Rev Med Suisse. 2(75):1861-1866.
15. Amoretti N, Thariat J, Nouri Y, Foti P, Hericord O, Stolear S, et al. (2013). Sémiologie des métastases osseuses en radiologie conventionnelle [Imaging of bone metastases]. Bull Cancer. 100(11):1109-1114.
16. Rouprêt M. (2012). Tumours of the bladder: what does the urologist expect from imaging? Diagn Interv Imaging. 93(4):291-296.
17. Pfister C, Roupret M, Neuzillet Y, Larré S, Pignot G, Quintens H, et al. (2013). [CCAFU Recommendations 2013: Bladder carcinoma]. Prog Urol. 3(Suppl 2):S105-S125.
18. Ploeg M, Aben KK, Kiemeney LA. (2009). The present and future burden of urinary bladder cancer in the world. World J Urol. 27(3):289-293.
19. Aapro M, Abrahamsson PA, Body JJ, Coleman RE, Colomer R, Costa L, et al. (2008). Guidance on the use of bisphosphonates in solid tumours: recommendations of an international expert panel. Ann Oncol. 19(3):420-432.
20. Henry DH, Costa L, Goldwasser F, Hirsh V, Hungria V, Prausova J, et al. (2011). Randomized, double-blind study of denosumab versus zoledronic acid in the treatment of bone metastases in patients with advanced cancer (excluding breast and prostate cancer) or multiple myeloma. J Clin Oncol. 29(9):1125-1132.
